| Marca | Schönbuch Sensor |
| Código | ICAA0808 |
| Ficha Tecnica |  Hoja de Datos |
| Connection: | 2 m/2 x 0,14 mm2 |
| Connection type: | cable |
| Outlet: | Namur Ausgang |
| Design: | M8 |
| Diameter: | M8x1 |
| Installation type: | flush |
| Length: | 25 mm |
| Reproducibility: | 0,01 mm |
| Switching distance: | 1,5 mm |
| Switching frequency: | 5000 Hz |
| Protection class: | IP 67 |
| Voltage type: | VDC |
| Voltage range: | 7,7 – 9 V |
| Temperature drift: | 10 °C |
| Environment temperature: | -25 bis 70 °C |
| Material: | nickel plated brass |
